Tractors>>MF375 S

	<<Back
Environment friendly, high performance Perkins 4.41 Engine Oil Cooler for effective cooling Gaseous Emissions under ECE R49 Robust Straddle Rear Axle Efficient oil-Immersed Disc Brakes Heavy-Duty Front Support Spring Suspension Deluxe Seat Easy Accessibility to Service points Heavy-Duty Spindle and Steering Arm Specious Operator's Area New Sheet Metal Style
Techinical Specifications

Technical Specification of Tractors MF375 S

PERFORMANCE Hide Show
Maximum engine power at 2,200 rpm 75 hp* Maximum torque at 1,400 engine rpm 212 Nm Maximum PTO power at 2,200 engine rpm 60 hp** *Manufacture's estimate **Certified to BS AU 141 a
ENGINE Hide Show
Make / Type Perkins / 4.41 No. of cylinders 4 Injection Direct Bore 101 mm Stroke 127 mm Capacity 4.1 Aspiration Natural Compression ratio 15.3:1 Starting aid Thermostart Throttle control Hand & foot Cooling Water Air cleaner Oil bath Air Pre cleaner Over bonnet, air swirl Fuel filter Dual, high capacity Exhaust Vertical, muffler under bonnet Oil cooler Water Cooled
ELECTRICS Hide Show
Voltage 12 V, negative earth Battery 96 Ah Starter 3 kW Alternator 32 Amp
CLUTCH Hide Show
Type Dual clutch Diameter 305 x 254 mm Lining material Cerametallic
TRANSMISSION Hide Show
Type Sliding Spur Number of gears 8 forward, 2 reverse Road speed at 2,200 engine rpm with 16.9/14x30 rear tyres.   Gear kph Forward 1 2.6 Forward 2 3.8 Forward 3 5.3 Forward 4 7.1 Forward 5 10.5 Forward 6 15.4 Forward 7 21.0 Forward 8 28.3 Reverse 1 3.6 Reverse 2 14.5
POWER TAKE OFF Hide Show
Type Live Engine speed @ 540 PTO rpm 1,789 rpm Shaft diameter 35 mm No. of splines 6
HYDRAULICS Hide Show
Functions Draft control, Position control, Response control, Constant Pumping Pump Type Reciprocating Ferguson pump Maximum oil flow 16 / min Maximum pressure 21 MPa at normal operating temperature Max. lift capacity with lower links horizontal 2,145 kg Lower Links Cat. 1 & 2 with interchageable balls
FRONT AXLE Hide Show
Type Box Section, Adjustable
STEERING Hide Show
Steering Manual
REAR AXLE AND BRAKES Hide Show
Axle type Straddle with epicyclic reduction Brake Type Oil immersed, multi disc Brakes actuation Mechanical
INSTRUMENTATION Hide Show
Gauges Tachometer, Hourmeter, Fuel level, Battery condition & Water temperature Warning lights Direction indicators, Battery charge, Headlight main beam,Low engine oil pressure, Brake lights
TYRES Hide Show
Front 7.50 - 16 (6 PR) Rear 16.9 / 14 - 30 (6 PR)
TRACK ADJUSTMENT Hide Show
Front 1,346- 1,854 mm Rear 1,423 - 2,134 mm
WEIGHT AND DIMENSIONS Hide Show
Weight Gross Weight 2,200 kg Dimensions Wheel base 2,100 mm Overall length 3,542 mm Overall width 1,870 mm Height Over exhaust 2,480 mm Over steering wheel/td> 1,815 mm Turning circle With brakes 6,140 mm Without brakes 6,900 mm Ground clearance 405 mm
CAPACITIES Hide Show
Fuel tank 60.0 Engine sump 7.5 Cooling system 15.2 Hydraulic system 36.0 Steering box 0.9 Oil bath air cleaner 0.7
STANDARD EQUIPMENT Hide Show
Chain stablisers, Check chains, Spring suspension seat, Flat top fenders, Standard tool box with set of tools, Weight frame without weights, Top link, Cat.-2 balls, Operator's manual
OPTIONAL EQUIPMENT Hide Show
Front end weights, 9 hole draw bar, Sun canopy
