Tractors>>MF260

	<<Back
High performance, fuel efficient, Perkins Turbocharged Engine Less Smoke emission due to better fuel burning Oil cooler added for effective cooling High PTO power for efficient operation of Tube Wells, Rotavators, Threshers etc. Robust Straddle Rear Axle Efficient oil immersed Disc Brakes Spring suspension deluxe seatp
Techinical Specifications

Technical Specification of Tractors MF260

PERFORMANCE Hide Show
Maximum engine power @2,250 rpm 60 hp* Maximum torque at 1,600 engine rpm 212 Nm Maximum PTO power at rated engine speed 48 hp** * Certified to BS AU 141a ** Manufacturer's estimate
ENGINE Hide Show
Make / Type Perkins T3.1524 No. of cylinders 3 Injection Direct Bore 91.4 mm Stroke 127.0 mm Capacity 2.5 Compression ratio 16.5 : 1 Starting aid Thermostart Throttle control Hand & foot Cooling Water Air cleaner Oil bath Air Pre cleaner Over bonnet, air swirl Fuel filter Dual, high capacity Exhaust Vertical Oil cooler Air Cooled , Fin Type
ELECTRICS Hide Show
Voltage 12 V, negative earth Battery 96 Ah Starter 2.2 kW Alternator 32 Amp
CLUTCH Hide Show
Type Dual clutch Diameter 305 x 254 mm
TRANSMISSION Hide Show
Type Sliding Spur Number of gears 8 forward, 2 reverse Road speed at 2,250 engine rpm with 14-9/13-28 rear tyres.   Gear kph Forward 1 2.7 Forward 2 3.9 Forward 3 5.4 Forward 4 7.2 Forward 5 10.7 Forward 6 15.6 Forward 7 21.3 Forward 8 28.7 Reverse 1 3.6 Reverse 2 14.5
POWER TAKE OFF Hide Show
Type Live Engine speed @ 540 PTO rpm 1,789 rpm Shaft diameter 35 mm No. of splines 6
HYDRAULICS Hide Show
Functions Draft control, Position control, Response control, Constant Pumping Pump Type Reciprocating Ferguson pump Maximum oil flow 16 / min Maximum pressure 19.25 MPa at normal operating temperature Max. lift capacity with lower links horizontal 1,415 kg Lower Links Cat. 1 & 2 with interchageable balls
FRONT AXLE Hide Show
Type Box Section, Adjustable
STEERING Hide Show
Steering Manual
REAR AXLE AND BRAKES Hide Show
Axle type Straddle with epicyclic reduction Brake Type Oil immersed, multi disc Actuation Mechanical, independent or locked together Parking brake Hand lever operated
INSTRUMENTATION Hide Show
Gauges Tachometer, Hourmeter, Fuel level, Battery condition & Water temperature Warning lights Direction indicators, Battery charge, Headlight main beam,Low engine oil pressure, Brake lights
TYRES Hide Show
Front 7.50 - 16 (6 PR Rear 14.9 / 13 - 28 (6 PR)
TRACK ADJUSTMENT Hide Show
Front 1,346- 1,854 mm Rear 1,423- 2,134 mm
WEIGHT AND DIMENSIONS Hide Show
Weight Gross Weight 1,890 kg Dimensions Wheel base 1,892 mm Overall length 3,260 mm Overall width 1,753 mm Height Over exhaust 2,145 mm Over steering wheel/td> 1,410 mm Turning circle With brakes 5,970 mm Without brakes 6,700 mm Ground clearance 338 mm
CAPACITIES Hide Show
Fuel tank 47.5 Engine sump 6.8 Cooling system 10.2 Hydraulic system 33 Steering box 0.9 Oil bath air cleaner 0.5
STANDARD EQUIPMENT Hide Show
Chain stablisers, Check chains, Spring suspension seat, Flat top fenders, Standard tool box with set of tools, Weight frame without weights, Top link, Cat.-2 balls, Operator's manual
OPTIONAL EQUIPMENT Hide Show
Front end weights, 9 hole draw bar, Sun canopy
